Analogue Video Doorphone Kit with 7 "Color LCD Screen / IP65 Outdoor Street Front
Main characteristics of the DS-KB2421-IM street front.
IR auto adaptive included for 2 meters.
Protection: IP65 (Note: requires protection as it is not for outdoor use)
720 x 576 @ 30 fps pinhole camera. 98 ° angle.
Dry contact relay output for opening.
Built-in audio IN / OUT.
Built-in speaker (Volume is not configurable).
Material: Aluminum
Power consumption: 3 W.
Operating temperature: -30º ~ 60º C (-22º ~ 140º F)
Dimensions: 128 × 42 × 24.8 mm (7.7 "× 5.2" × 0.7 ").
C haracteristics of monitor street DS-KH2220.
7 "color screen.
Resolution: 800 x 400.
Audio IN / OUT
Built-in Microphone and Speaker (Volume is not configurable).
Supports street front monitoring and one analog camera per monitor.
Physical and Electrical Characteristics:
Material: Aluminum.
Power supply: 12 Vdc / 5W (Included).
Operating temperature: -10º ~ 55º C (14º ~ 131º F)
Dimensions: 195.8 × 132.8 × 18.39mm (7.7 "× 5.2" × 0.7 ")
Outstanding Features:
Easy 4-wire installation we can reach a maximum distance of 100 meters with 22 cal cable.
It is not recommended to use UTP cable for installation.
Scopes:
* Expandable only up to 3 monitors (DS-KH2220).
* Expandable only up to 2 street fronts (DS-KB2421-IM).
- Warranty: 1 Year
* DOES NOT INCLUDE INSTALLATION
* PUBLISHED PRICE COUNTED.
Analog Video Doorphone Kit with 7 "Color LCD Screen
Brand: HIKVISION
Model: DSKIS20
SAT code: 43221525
